Room status signalling unit 3M - 21125

21125
Wiring devices / Traditional wiring devices / EIKON / Devices

Room status signalling unit 3M
Electronic unit, 8 non-polarised inputs, 7 solid state outputs for non-polarised contacts, configurable RGB LED backlighting, 9-32VDC power supply, for external/internal hotel room or cabin applications, to be completed with labels and Eikon Tactil cover plate - 3 modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (1312 kb)
• Manuale installatore (914 kb)
• Installer manual (863 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Illumination insert for domestic switching devices

Application
Other

Lamp type
LED

Colour light source
Other

Lamp holder
Other

Nominal current
100,0000 A

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352608283

1 NR

8.5x3.9x8.6 [cm]

103.7 [g]

8007352612303

10 NR

20.7x18.5x9.6 [cm]

1,153 [g]
