Roller blind laths electronic switchCode 21174

21174

Wiring devices / Traditional wiring devices / EIKON / Devices

Roller blind laths electronic switch

Electronic switch for roller shutter with laths orientation with cosφ 0,6 2 A 230 V~ motor relay output, control with a single electronic switch or from peripheral remote controls, to complete with signalling tags and Eikon Tactil cover plate

Product Status

3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (1362 kb)
• Installation diagrams (1100 kb)

Video

• Installing the Eikon Tactil stand-alone

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Electronic insert for domestic switching devices

Model
Other

Assembly arrangement
Other

Number of modules (module system)
1

Radio-controlled
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352494268

1 NR

5.1x4.3x5.3 [cm]

54.7 [g]

8007352494275

10 NR

26.9x11.6x4.9 [cm]

611.2 [g]
