Auxiliary emergency LED lamp 1MCode 30398
- 30398
- Wiring devices / Traditional wiring devices / LINEA / Devices
- Auxiliary emergency LED lamp 1M
- Auxiliary emergency lamp and controllable step marker lamp, high efficiency LEDs 100-240 V~ 50/60 Hz, can also be used as a courtesy light or a step marker lamp controlled by an external 1-way switch, non-replaceable rechargeable Li-ion battery, range of 2.5 hours, neutral
- Product Status
- 3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Luminaires
Luminaires
Class
Emergency luminaire
Emergency luminaire
Mounting method
Built-in
Built-in
Function
Escape route lighting
Escape route lighting
Suitable for labelling type
Other
Other
With pictogram
No
No
With remote switch connection
Yes
Yes
With remote control
No
No
Battery technology
Lithium-ion
Lithium-ion
Lamp type
LED not exchangeable
LED not exchangeable
With light source
Yes
Yes
Suitable for number of light sources
1
1
Lamp holder
Other
Other
Number of lighting heads
1
1
Housing material
Plastic
Plastic
Housing colour
Colourless
Colourless
Material cover
Without cover
Without cover
Voltage type
AC
AC
Nominal voltage
100,00 - 240,00 V
100,00 - 240,00 V
Type of control gear
Not required
Not required
Exchangeable control gear
No
No
Light distributor
Other
Other
Degree of protection (IP)
IP40
IP40
Degree of protection (NEMA)
Other
Other
Protection class according to IEC 61140
II
II
Max. system power
1,00 W
1,00 W
Nominal operation time
250,00 - 251,00 h
250,00 - 251,00 h
Width
22,20 mm
22,20 mm
Height/depth
44,30 mm
44,30 mm
Length
52,80 mm
52,80 mm
Outer diameter
0 mm
0 mm
Built-in width
22,20 mm
22,20 mm
Built-in height/depth
38,60 mm
38,60 mm
Built-in length
52,80 mm
52,80 mm
Built-in diameter
0 mm
0 mm
Type of wiring
Ending
Ending
Number of poles
0
0
Conductor cross section
250,00 mm2
250,00 mm2
Connection type
Screw connection
Screw connection
Minimum order quantity: 1 NR
Barcode
8007352704817
1 NR
6x5.4x5.2 [cm]
43.2 [g]
8007352704824
10 NR
23.5x12.5x6.5 [cm]
510.2 [g]
8007352713307
90 NR
37.5x30x21 [cm]
5,000 [g]
