Bullet AHD cam 3Mpx 6-22mm lens - 46516.622C

Pdf
46516.622C

ELVOX CCTV / AHD / Bullet cameras

Bullet AHD cam 3Mpx 6-22mm lens
Day & Night AHD Bullet camera, 3 Mpx resolution, 1/3in sensor, mechanical IR filter, 6-22mm varifocal lens, CsC function, 0 lux IR in ON sensitivity, protection degree IP66, IR illuminator with range up to 50m, Smart-IR, automatic functions: BLC, 2DNR, AGC, WHITE-BAL, D-WDR. 12 V DC 700 mA power supply, complete with bracket and protected cable outlet. Dimensions 306(W) x 76(Ø) mm. Weight 744 g

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Class group
Alarm installations, emergency call and signalling
Class
Camera for monitoring system
Mounting method
Wall/ceiling
Scope of application
Universal
Picture system
PAL
Property picture system
Colour
Colour
White
Wireless
No
With IR lamp
Yes
Vandal proof
No
Supply voltage
12,00 - 12,01 v
Voltage type
DC
Diameter
7.600 mm
Height
76,00 mm
Width
7.600 mm
Depth
306,00 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8013406307224
1 NR
27.5x17x12.5 [cm]
925.5 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
