Sound System interphone power supp. 230VCode 938A

Download as PDFPDF

938A: ELVOX Door entry system / Multi-wire video entry system / System components / Power supply units
Sound System interphone power supp. 230V: Power supply unit for Sound System interphone with 15 V output, power supply 230 V~ 50/60 Hz 55 VA, entrance panel call function, with triple note generator for calls from the external entrance panel, the landing or intercom units, for electronic units 0930/000.04 and 930A, installation on DIN rail (60715 TH35), occupies 8 modules size 17.5 mm
Product Status: 3 - Active

Sheets, Manuals, Documentation

Drawings

Class group
Communication technique (components and systems)

Class
Power supply door communication

Application
Other

Input voltage
230 V

Type of current
AC

Output voltage
15,00 V

Degree of protection (IP)
IP20

Height
90,00 mm

Width
140,00 mm

Depth
63,80 mm

Installation technique
Multi-wire system

Integrated door opening circuit
Yes

Control function
No

Evaluation function
No

Service indication
No

Mounting method
Other

Programming lock
No

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

8013406134998

14.5x9.5x8 [cm]

1,009 [g]

8007352804166

15 NR

39.5x30x17 [cm]

15,517 [g]

8013406225993

20 NR

37x32x21.5 [cm]

20,562 [g]
