KLYS 9CD SLAVE up&over operator 24V 9m2
Non-reversible 24 V SLAVE electromechanical operator for up-and-over doors up to 12 m2 in conjunction with the KLYS 9CD MASTER operator.

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Manuale installatore (4680 kb)

Class group
Gate operators, pumps and ventilators

Class
Garage door operator

Nominal voltage
24 V

Max. door/gate width
5.000 mm

Number of safety inputs
0

With rail runner
Yes

With interior push-button
No

Separate control unit housing
No

Soft run
Yes

Cycle counter
No

Door status indication
No

Defined running direction control
Yes

Connection for red traffic light
No

Suitable for collective garages
Yes

Floating relay output
No

With manual transmitter
No

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8013406228222

1 NR

25x77x19.5 [cm]

11,000 [g]
