KIT HIDDY 350D under.24V 3,5m for Wi-Fi - EK11.24.W.EXP

Pdf
EK11.24.W.EXP

ELVOX Gates / Actuator KIT / Underground swing

KIT HIDDY 350D under.24V 3,5m for Wi-Fi
HIDDY 350D kit for swing gate leaves up to 3.5 m, 200 kg. Contents: 2x EIM2.24 HIDDY 350D non-reversible 24 V electromechanical linear operators for underground installation, 1x ECA5.W 24 V control panel with display ready for communication with Smartphone and Tablet, 1x ELA5 12/24 V flashing LED with built-in aerial, 2x ETRN4 4-channel 433 MHz rolling code remote controls, 1x EFA1 pair of 180°orientable photocells, 1x ZX20 warning sign

Product Status
4 - Active

Kit components

Class group
Gate operators, pumps and ventilators
Class
Swing gate operator
Model
2 wings
Max. width of door/gate wing
3.500 mm
Max. weight of door/gate leaf
400 kg
Type of current
DC
Motor voltage
24 v
Limit switch
Gate stop
Frequency radio receiver
433 MHz
With motor control unit
Yes
With post fittings
No
With wing fittings
No
With key-switch
No
With radio receiver
Yes

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8013406305169
1 NR
48x36x28 [cm]
28,000 [g]
