Box for screed for turret 12M - V54912

Pdf
Vimar - V54912 - Box for screed for turret 12M
Vimar - V54912 - Box for screed for turret 12M

V54912
System infrastructure / Enclosures and control units / Floor mount turrets / Flush mounting

Box for screed for turret 12M

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. V54912
PNG DXF
rear view art. V54912
PNG DXF
3D view art. V54912
PNG DXF
Class group
Subfloor systems
Class
Device installation insert for subfloor installation
Cover model
Rectangular
Number of inlets
8
Number of device cups
1
Number of socket outlets with protective contact CEE 7/3 (type F)
0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)
0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)
0
Number of socket outlets British Standard BS1363
0
With cable outlet in cover
Yes
Lockable cover
Yes
Housing material
Stainless steel
Surface protection housing
Untreated
Material cover
Stainless steel
Surface protection cover
Untreated
Surface treatment cover
Untreated
Degree of protection (IP)
Other
Protective frame carpeting
Yes
Colour
Other
Suitable for indoor installation
Yes
Suitable for outdoor installation
No
Suitable for subfloor duct
Yes
Suitable for hollow floor
No
Suitable for double floor built-in
Yes
Suitable for concrete installation
Yes
Suitable for floors in computer rooms
Yes
Suitable for wet cleaning
Yes
Outer width
310,0 mm
Outer length
230,0 mm
Length built-in dimension
230,0 mm
Width built-in dimension
310,0 mm
Min. built-in depth
105,0 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352735286
1 NR
32x24x13 [cm]
3,585 [g]
