IP44 junction box 65x35mm - V55001

Pdf
V55001

Enclosures and mounting boxes / Junction surface mounting boxes / With cable outlet

IP44 junction box 65x35mm
Surface mounting junction box with cable entries, snap closed cover, RAL 7035 grey. Dimensions ø 65x35 mm

Product Status
3 - Active

Class group
Connection devices
Class
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
Equipped with
None
Shape
Round
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
No
Length
65,00 mm
Width
81,00 mm
Depth
39,00 mm
Diameter
65 mm
Tackable
No
Number of inlets
4
Type of housing feed-through
Trimmable step membrane
Material
Plastic
Halogen free
No
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP44
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Castable
No
With casting compound
No
Sealable
No
Rated insulation voltage Ui
450 v
Circuit integrity
None
With screening
No
Weatherproof
Yes
Operating temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 6 NR

Barcode

Barcode Qty 1 NR
8007352076938
1 NR
8.2x8.2x3.9 [cm]
49.28 [g]
Barcode Qty 6 NR
8007352076945
6 NR
8.2x8.2x24 [cm]
295.67 [g]
Barcode Qty 114 NR
8007352115699
114 NR
38.5x29x30 [cm]
6,130.67 [g]
