V55205
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting
IP56 junction box 120x80x50mm
Surface mounting junction box with undrilled walls, blind cover closed with stianless steel screws, RAL 7035 grey. Dimensions 120x80x50 mm
Product Status
3 - Active
Class group
Electrical installation, isolation and connection material
Electrical installation, isolation and connection material
Class
Box/housing for surface mounting on the wall/ceiling
Box/housing for surface mounting on the wall/ceiling
Model
Junction box
Junction box
Equipped with
None
None
Max. conductor cross section
0,00 mm2
0,00 mm2
Shape
Rectangular
Rectangular
Mounting method
Wall-/ceiling mounting
Wall-/ceiling mounting
Mounting in the soil
No
No
Mounting under water
No
No
For tube diameter
20/25 mm
20/25 mm
Number of inlets
0
0
Inlet from the rear
No
No
Length
120,00 mm
120,00 mm
Width
148,00 mm
148,00 mm
Depth
56,00 mm
56,00 mm
Diameter
0,00 mm
0,00 mm
Connectable
No
No
Type of housing feed-through
Trimmable step membrane
Trimmable step membrane
Material
Plastic
Plastic
Halogen free
No
No
Surface protection
Untreated
Untreated
Colour
Grey
Grey
Cover model
Blind cover
Blind cover
Transparent cover
No
No
Castable
No
No
Cover attachment
Screwed
Screwed
Casting compound included
No
No
Sealable
No
No
Rated insulation voltage Ui
450 V
450 V
Circuit integrity
None
None
With screening
No
No
Weatherproof
Yes
Yes
Working temperature
0 - 60 °C
0 - 60 °C
Explosion-tested version
No
No
For Ex-zone gas
None
None
For Ex-zone dust
None
None
Minimum order quantity: 40 NR
Barcode
8007352079397
1 NR
12.9x8.9x5.6 [cm]
112 [g]
8007352115750
40 NR
38.5x29x30 [cm]
4,566 [g]
