IP56 junction box 380x300x120mm - V55210

Pdf
V55210

Enclosures and mounting boxes / Junction surface mounting boxes / With smooth walls

IP56 junction box 380x300x120mm
Surface mounting junction box with undrilled walls, blind cover closed with stianless steel screws, RAL 7035 grey. Supplied with two hinges. Dimensions 380x300x120 mm

Product Status
3 - Active

Sheets, Manuals, Documentation

Class group
Connection devices
Class
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
Equipped with
None
Shape
Rectangular
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
No
Length
380,00 mm
Width
334,00 mm
Depth
129,00 mm
Diameter
0 mm
Tackable
No
Number of inlets
0
Type of housing feed-through
None
Material
Plastic
Halogen free
No
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP56
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Castable
No
With casting compound
No
Sealable
No
Rated insulation voltage Ui
450 v
Circuit integrity
None
With screening
No
Weatherproof
Yes
Operating temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None
Minimum order quantity: 4 NR

Barcode

Barcode Qty 1 NR
8007352079151
1 NR
31.6x40x12.9 [cm]
1,665.07 [g]
Barcode Qty 4 NR
8007352079168
4 NR
42x61x35 [cm]
7,664.67 [g]
