Caja derivación empotrable 154x92x70mm - V70004

Pdf
V70004

Cajas / Cajas de derivación empotrables / Cajas

Caja derivación empotrable 154x92x70mm
Cajas de derivación empotrable con tapa blanca y tornillos de fijación. Dimensiones 154x92x70 mm

Estado producto
3 - Activo

Podría interesarte también

Dibujos

Class group
Connection devices
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush mounted (plaster)
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Connectable
Yes
Equipped with
None
Diameter
0 mm
Length
154,00 mm
Width
179,00 mm
Depth
0,00 - 70,00 mm
Internal depth
70,00 mm
For number of electric fittings
0
Mounting switching equipment
Spread
With screws
No
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
Other
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
14
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
With nail lugs
No
Special application
None

00. Marcado CE - UE

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 55 NR

Código de barras

Barcode Qty 1 NR
8007352082021
1 NR
17,9x11,8x7,5 [cm]
132 [g]
Barcode Qty 55 NR
8007352115613
55 NR
59x39x44 [cm]
8.300 [g]
