Plate 6M (2+2+2)x71 techn.matt dove grey - 09666.12

Pdf
Vimar - 09666.12 - Plate 6M (2+2+2)x71 techn.matt dove grey
Vimar - 09666.12 - Plate 6M (2+2+2)x71 techn.matt dove grey
09666.12

Neve Up / Cover plates / Snap fixing technopolymer cover plates

Plate 6M (2+2+2)x71 techn.matt dove grey
6-module cover plate (2+2+2, distance between centres 71 mm), technopolymer, matt dove grey

产品状态
3 - Active

您可能也感兴趣

09602.1
09602.1 - Frame 2M +claws 71mm
09603.1
09603.1 - Frame 2M wihtout screws 71mm

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
6
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Other
RAL-number (similar)
1019
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
224,00 mm
Height
86,00 mm
Depth
8,50 mm
Built-in width
224,00 mm

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352660489
1 NR
25x9x0.5 [cm]
33.07 [g]
Barcode Qty 5 NR
8007352660496
5 NR
10x4.5x29 [cm]
205 [g]
Barcode Qty 190 NR
8007352706170
190 NR
59.5x38.5x26.5 [cm]
7,790 [g]
