Dividing screen for boxes 8M yellow - V71552

Pdf
Vimar - V71552 - Dividing screen for boxes 8M yellow
Vimar - V71552 - Dividing screen for boxes 8M yellow

V71552
System infrastructure / Enclosures and control units / Connector block boxes / Installation accessories

Dividing screen for boxes 8M yellow
Horizontal dividing screen for V71318 and V71718 flush mounting boxes, yellow. Allows to realize electrically separated compartments inside the box

产品状态
3 - Active

您可能也感兴趣

V71318
V71318 - Flush mounting box 8M light blue
V71718
V71718 - Flush-mount box 8M f/hollow walls blue

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Connection material (electrotechnical)
Class
Separation plate for junction box
Partition width
123,00 mm
Partition height
47 mm
Material
Plastic
Surface protection
Other

00. CE Marking - EU

01. IMQ - Italy

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352425620
1 NR
12.2x4.8x0.2 [cm]
8.9 [g]
Barcode Qty 20 NR
8007352441743
20 NR
14.4x9x6 [cm]
214.5 [g]
