Climate dimmer for heat systemCode 01465

Download as PDFPDF

01465: Smart systems&products / By-me Plus / Shared components / DIN devices
Climate dimmer for heat system: HVAC control for heating systems, class II temperature control device (contribution 2%), power supply 120-230 V~ 50/60 Hz, 3 inputs for PT100, PT1000 and NTC probes, 1 mixer valve control output, 1 output 0-10 V or (0)4-20 mA, 1 change-over relay output 8 A 230 V~, installation on DIN rails (60715 TH35), occupies 6 modules size 17.5 mm
Product Status: 3 - Active

You may also be interested in

02971 - Home autom.dial thermostat 2M grey

02965.1 - Wired temperature sensor 120°C 3m

Sheets, Manuals, Documentation

Video

Climaenergy EasyTool Professional

Drawings

Class group
Stats, switches and controllers

Class
Room thermostat

Temperature readable
No

Mounting method
DRA (DIN-rail adaptor)

Max. contact voltage
230 V

Degree of protection (IP)
IP20

Colour
Other

Height
109,70 mm

Width
107,70 mm

Depth
59,00 mm

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

8007352512375

11.7x10.8x7.1 [cm]

308.8 [g]
