By-me sound cable2x0,5 LSZH Eca100m blue - 01840.E.B

Pdf
01840.E.B

Surface mounting equipments / Systems / Cable

By-me sound cable2x0,5 LSZH Eca100m blue
By-me system Bus cable for sound system, 2x0,50 mm2 with LSZH sheath, CPR Eca class, suitable for installation with I Category power supply cables (U0 = 400 V), blue - 100 m reel

Product Status
3 - Active

Class group
Cables
Class
Data and communication cable (copper)
Nominal cross section conductor
0,50
Conductor category
Class 5 = flexible
Number of cores
2
Stranding element
Pairs
Core insulation material
Other
Core identification
Colour
Screen over stranding element
None
Screen over stranding
None
Material outer sheath
Other
Colour outer sheath
Blue
Halogen free (acc. EN 60754-1/2)
Yes
Flame retardant
In accordance with EN 60332-1-2
Low smoke (acc. EN 61034-2)
Yes
Outer diameter approx.
5,40 mm
Permitted cable outer temperature during assembling/handling
-20 - 80 °C
Category
Other
Minimum order quantity: 100 M

Barcode

Barcode Qty 1 M
8007352574571
1 M
100x0.54x0.54 [cm]
33.03 [g]
Barcode Qty 100 M
8007352574564
100 M
29x29x7.5 [cm]
3,136.67 [g]
