By-me Marine 2x0,5 LSZH Eca cable - 100m - 01841.E

Pdf
01841.E

Surface mounting equipments / Systems / Cable

By-me Marine 2x0,5 LSZH Eca cable - 100m
By-me system Bus cable, shielded, 2x0,50 mm2 with LSZH sheath, CPR Eca class, suitable for installation with I Category power supply cables (U0 = 400 V), for marine application, white - 100 m reel

Product Status
3 - Active

Class group
Cables
Class
Data and communication cable (copper)
Nominal cross section conductor
0,50
Conductor category
Class 5 = flexible
Number of cores
2
Stranding element
Pairs
Core insulation material
Other
Core identification
Colour
Screen over stranding element
Foil
Screen over stranding
Foil
Material outer sheath
Other
Colour outer sheath
White
Halogen free (acc. EN 60754-1/2)
Yes
Flame retardant
In accordance with EN 60332-1-2
Low smoke (acc. EN 61034-2)
Yes
Outer diameter approx.
5,40 mm
Permitted cable outer temperature during assembling/handling
-20 - 80 °C
Category
Other
Minimum order quantity: 100 M

Barcode

Barcode Qty 1 M
8007352574588
1 M
100x0.54x0.54 [cm]
34.3 [g]
Barcode Qty 100 M
8007352574595
100 M
29x29x7.5 [cm]
3,430 [g]
