LED emergency lamp 120V Arké/Plana 7M - 02660.1.120

02660.1.120
Wiring devices / Traditional wiring devices / Shared components / Devices

LED emergency lamp 120V Arké/Plana 7M
Emergency lighting device with high-efficiency LED, supply voltage 120 V~ 50-60 Hz, rechargeable Ni-Cd battery, built-in mounting frame for 6/7-module flush mounting boxes. To complete with Arké or Plana cover plate

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• FI - Foglio istruzioni ZIS_49400456A0 (1462 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Luminaires

Class
Emergency luminaire

Monitoring equipment
None

With remote switch connection
Yes

Power supply system
Peripheral (individual battery)

Battery quality
NiCd

Lamp type
LED not exchangeable

With light source
Yes

Housing colour
White

Voltage type
AC

Nominal voltage
120,00 - 120,01 V

Degree of protection (IP)
IP40

Protection class
II

Max. system power
5,00 W

Rated luminous flux according to IEC 62722-2-1
75

Width
206,00 mm

Height/depth
70,60 mm

Length
73,00 mm

Built-in width
206,00 mm

Built-in height/depth
43,00 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352442856

1 NR

22.5x9.7x10 [cm]

370 [g]
