Vimar - 03309 - Wall mount cabinet 10in 9u 368x316x462mm
Vimar - 03309 - Wall mount cabinet 10in 9u 368x316x462mm

03309
System infrastructure / Netsafe structured wiring / Surface mounting components / Carpentry

Wall mount cabinet 10in 9u 368x316x462mm
Wall mount cabinet for 10 patch panels of up to98 rack units, RAL 7035. Dimensions 368x316x462 mm

Product Status
3 - Active

Drawings

view encumbered art. 03309
PNG DXF
rear view art. 03309
PNG DXF
3D view art. 03309
PNG DXF
Class group
Cabinet enclosures
Class
Network/server enclosure
Type of profile rail
L-shaped
Number of doors
1
Type of ventilation
None
Width
368 mm
Height
460 mm
Depth
317,60 mm
Modular spacing
254 mm (10 inch)
Number of height units
9
With roof plate
Yes
With earthing
Yes
With front door
Yes
With rear door
No
With sidewall
Yes
With base
No
Material
Other
Surface finishing
Lacquered
Colour
Grey
Model
With swing frame
RAL-number
0
Demountable
No
Degree of protection (IP)
IP20
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352561663
1 NR
36.8x31.6x46.2 [cm]
11,000 [g]
