16 A IoT connected actuator whiteCode 09593
- 09593
- Wiring devices / View Wireless wiring devices / NEVE UP / Devices
- 16 A IoT connected actuator white
- View Wireless connected electronic control device with NO 16(3,5)A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, white
- Product Status
- 3 - Active
You may also be interested in
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (838 kb)
- Foglio istruzioni Full (459 kb)
- Notice technique Full (549 kb)
- Ficha de instrucciones Full (455 kb)
- Full instructions sheet (453 kb)
- Φυλλάδιο οδηγιών Full (619 kb)
- Anweisungsblatt Full (456 kb)
- ورقة الإرشادات Full (517 kb)
- Manuale app View Wireless (19693 kb)
- Manuel appli View Wireless (43543 kb)
- Manual app View Wireless (43542 kb)
- Manual View Wireless app (42589 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43825 kb)
- Installationsanleitung View Wireless (43598 kb)
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Switch actuator for bus system
Switch actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
Yes
Yes
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequency bidirectional
Yes
Yes
Mounting method
Flush-mounted
Flush-mounted
Width in number of modular spacings
0
0
Local operation/hand operation
Yes
Yes
With LED indication
Yes
Yes
Number of digital inputs
0
0
Max. switching power
0 W
0 W
Max. switching power LED
0 W
0 W
Output power
0 W
0 W
Suitable for C-load
No
No
Max. number of switching contacts
1
1
Max. switching current
16 A
16 A
Rated current
16 A
16 A
Rated operating voltage
100,00 - 240,00 V
100,00 - 240,00 V
Different phases connectable
No
No
With bus connection
No
No
Bus module detachable
No
No
Modular expandability
No
No
Degree of protection (IP)
IP40
IP40
37. Marking - Morocco
40. Bluetooth technology
42. Zigbee certified
47. Works with SmartThings
Minimum order quantity: 1 NR
Barcode
8007352732247
1 NR
5.2x3.5x5.3 [cm]
54 [g]
8007352732254
60 NR
27x23x12.5 [cm]
3,422 [g]
