2-button 2P 10AX 2-way switch white - 14060

Pdf
14060

Plana / Devices / Devices - other functions

2-button 2P 10AX 2-way switch white
2-button 2P 10 AX 250 V~ 2-way switch (6 terminals) with directional arrows and central OFF position, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

You may also be interested in

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Other
Number of rockers
1
Number of modules (module system)
1
Number of poles
2
Nominal voltage
250 v
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
42,50 mm

00. CE Marking - EU

07. INGCER - Chile

10. EAC Eurasian Customs Union

19. NOM - Mexico

20. IRAM - Argentina

31. TISI - Thailand

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352108660
1 NR
5.1x2.8x5.3 [cm]
42.8 [g]
Barcode Qty 10 NR
8007352263543
10 NR
14.4x11.6x6 [cm]
473.8 [g]
Barcode Qty 120 NR
8007352626843
120 NR
36.5x33x13.5 [cm]
6,392 [g]
Question: Can the product be fully opened by pressing the push button once?
Answer: Yes. Upon pressure, the product even remains on after you release it, allowing the continuous closure of the circuit to which it is connected without having to hold it down.
