14300.01
Wiring devices / Traditional wiring devices / PLANA / Devices
TV-RD-SAT single conn.outlet white
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, single connection, with male connector, connection attenuation 1 dB, white. Allows the passage of d.c. current and control signals (24 V 500 mA max).
Product Status
3 - Active
Drawings
Class group
Antenna and satellite technique
Antenna and satellite technique
Class
Antenna socket box
Antenna socket box
Model
End socket
End socket
Cover
None
None
Tap loss at 860 MHz
0,10 dB
0,10 dB
Tap loss at 2150 MHz
0,20 dB
0,20 dB
Number of outlets
1
1
Suitable for remote power supply
Yes
Yes
Type of fastening
Snap mounting (engagement)
Snap mounting (engagement)
Colour
White
White
RAL-number (similar)
9003
9003
Material
Plastic
Plastic
Minimum order quantity: 20 NR
Barcode
8007352101234
1 NR
4.1x2.8x5.3 [cm]
43.4 [g]
8007352101241
20 NR
21.4x11.6x6 [cm]
868 [g]
8007352361386
200 NR
30.5x26x22 [cm]
9,020 [g]
8007352750401
8,800 NR
120x80x105 [cm]
396,704 [g]
