Three rocker pushbuttons+MASTER actuator - 14549

Pdf
14549

Plana / Systems / Domotics - devices

Three rocker pushbuttons+MASTER actuator
Three rocker push buttons and actuator for MASTER dimmer 230 V~ 50 Hz for: 40-300 W incandescent lamps, 40-200 VA electronic transfomers, 10-120 W CFL lamps, 3-120 W LED lamps and LED electronic transfomers, protection fuse, to complete with interchangeable 1- or 2-module buttons - 3 modules

Product Status
42 - Will be discontinued

Alternative products

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Contacts
Other
Number of poles
1
Feedback-signal contact
No
Number of rockers
3
Number of modules (module syst
3
With lighting
Yes
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (akin)
9003
Transparent
No
Label space/information surfac
Yes
Imprint
None
Suitable for degree of protect
IP40
Nominal voltage
230 v
Width of device
67,30 mm
Height of device
49,00 mm
Depth of device
44,45 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352458635
1 NR
11.2x9.6x9.8 [cm]
155.8 [g]
