1P 16AX 2-way switch 2M grey - 17003.G

Pdf
Vimar - 17003.G - 1P 16AX 2-way switch 2M grey
Vimar - 17003.G - 1P 16AX 2-way switch 2M grey

17003.G
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 2-way switch 2M grey
1P 16 AX 250 V~ 2-way switch, grey - 2 reduced modules. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Lighting
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Monitoring contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
21,80 mm
Device height
50,10 mm
Device depth
32,50 mm
Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

19. NOM - Mexico

28. NSW - Australia

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352084247
1 NR
5.1x4.3x5.3 [cm]
36.87 [g]
Barcode Qty 20 NR
8007352084254
20 NR
26.9x11.6x9 [cm]
817.07 [g]
