2P+E 10A P11 outlet grey - 17031

Pdf
17031

Idea / Reduced module devices / Italian standard socket outlets

2P+E 10A P11 outlet grey
2P+E 10 A 250 V~ SICURY socket outlet, Italian standard P11, grey - reduced module

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P11
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
Without imprint
Connection type
Screwed terminal
With hinged lid
No
With child-protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (akin)
7015
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
For heavy conditions (in accordance with VDE)
No
Impact strength
Other
Width of device
21,80 mm
Height of device
50,10 mm
Depth of device
36,50 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352005679
1 NR
4.1x2.8x5.3 [cm]
27.33 [g]
Barcode Qty 20 NR
8007352005686
20 NR
21.4x11.6x6 [cm]
603.47 [g]
Barcode Qty 200 NR
8007352637337
200 NR
30.5x25.5x22.5 [cm]
6,334 [g]
