Switched 2P+E 15A English outlet Metal - 19217.M

Pdf
Vimar - 19217.M - Switched 2P+E 15A English outlet Metal
Vimar - 19217.M - Switched 2P+E 15A English outlet Metal
19217.M

Arké Metal / Devices / Controlled socket outlets

Switched 2P+E 15A English outlet Metal
2P switched 2P+E 15 A 250 V~ SICURY socket outlet, English standard, with built-in frame for square British standard mounting boxes, to complete with 3-module British standard cover plate, Metal

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
British Standard
With built-in USB power supply
No
Number of modules (module system)
3
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Aluminium
RAL-number (similar)
9007
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
With on/off switch
Yes
With loop through function
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
82,50 mm
Height of device
82,50 mm
Depth of device
37,60 mm

00. CE Marking - EU

08. ASTA - UK

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352590687
1 NR
8.5x3.9x8.6 [cm]
105.3 [g]
Barcode Qty 10 NR
8007352590694
10 NR
20.6x18.5x9.6 [cm]
1,164 [g]
