19465.AB
Wiring devices / Traditional wiring devices / ARKÉ / Devices
Vertical badge switch antibact.grey
Electronic badge switch with vertical pocket, 16 A 250 V~ change-over relay output, supply voltage 230 V~ 50-60 Hz, 24 V~ 50-60 Hz and 24 Vdc (SELV), antibacterial material, grey - 3 modules. Provided without ISO card (badge)
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Access control system
Access control system
Standalone
Yes
Yes
Networkable
No
No
PC-binding
No
No
Type of interface
None
None
Type of reading technique
Data medium
Data medium
Signalling
None
None
Mounting method
Flush-mounted
Flush-mounted
Operating voltage AC 50 Hz
250,00 - 250,01 V
250,00 - 250,01 V
Operating voltage AC 60 Hz
250,00 - 250,01 V
250,00 - 250,01 V
Operating voltage DC
24,00 - 24,01 V
24,00 - 24,01 V
Operating temperature
5 - 45 °C
5 - 45 °C
Degree of protection (IP)
IP20
IP20
Colour
Grey
Grey
Model
Other
Other
Material
Plastic
Plastic
Width
67,50 mm
67,50 mm
Height
49,00 mm
49,00 mm
Depth
56,80 mm
56,80 mm
Minimum order quantity: 1 NR
Barcode

8007352652705
1 NR
5.7x5.3x7.7 [cm]
86.9 [g]

8007352738539
5 NR
21.4x11.6x6 [cm]
491.3 [g]

8007352738546
50 NR
30.5x25.5x22.5 [cm]
5,253 [g]
