Pocket switch NFC/RFID AGB Metal - 19468.M

Pdf
19468.M

Arké Metal / Systems / Access control system

Pocket switch NFC/RFID AGB Metal
NFC/RFID electronic transponder card reader for installation inside the room, compatible with AGB Electronic Solutions for Hotels, vertical pocket, 1 relay output 10 A 230 V~ NO (NON SELV), 1 relay output 4 A 230 V~ NO (NON SELV), power supply 120-230 V~ 50/60 Hz, pocket backlighting for visible in darkness, Metal - 3 modules. Supplied without card (badge)

Product Status
3 - Active

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
Buzzer
Mounting method
Flush mounted (plaster)
Operating voltage at AC 50 Hz
120,00 - 230,00 v
Operating voltage at AC 60 Hz
120,00 - 230,00 v
Operating temperature
0 - 40 °C
Degree of protection (IP)
IP20
Colour
Silver
Material
Plastic
Width
67,30 mm
Height
49,00 mm
Depth
50,30 mm

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352601284
1 NR
5.2x5.7x7.6 [cm]
97.1 [g]
Barcode Qty 5 NR
8007352602502
5 NR
21.4x11.6x6 [cm]
541.8 [g]
