2P NO 16A push button +key grey - 20086

Pdf
20086

Eikon / Devices / Devices - other functions

2P NO 16A push button +key grey
2P NO 16 A 250 V~ key-operated push button, key removable in OFF position only, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Contacts
2 make contacts (NO)
Number of poles
2
Feedback-signal contact
No
Number of rockers
0
Number of modules (module system)
1
With lighting
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
7024
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
43,50 mm
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352253445
1 NR
5.1x2.8x5.3 [cm]
53.93 [g]
Barcode Qty 10 NR
8007352253452
10 NR
14.4x11.6x6 [cm]
586.2 [g]
