Axial 1P 16AX 1-way switch 2M grey - 20101.2

Pdf
20101.2

Eikon / Devices / Basic devices

Axial 1P 16AX 1-way switch 2M grey
Axial 1P 16 AX 250 V~ 1-way switch, lightable, replaceable button, grey - 2 modules. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

You may also be interested in

Class group
Domestic switching devices
Class
Switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
7024
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
44,00 mm
Built-in depth
34,50 mm
Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352459786
1 NR
5.1x4.8x5.3 [cm]
41.1 [g]
Barcode Qty 10 NR
8007352459793
10 NR
24.7x11x6.2 [cm]
477.9 [g]
