Relay actuator grey - 20535

Pdf
20535

Eikon / Systems / Domotics - devices

Relay actuator grey
Actuator with 16 A 120-230 V~ change-over relay output, grey - 2 modules

Product Status
42 - Will be discontinued

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
No
Mounting method
Flush mounted (plaster)
Width in number of modular spacings
2
Local operation/hand operation
No
With LED indication
Yes
Suitable for C-load
Yes
Max. number of switching contacts
1
Rated current
16 A
Rated operating voltage
120,00 - 230,00 v
Different phases connectable
No
With bus connection
Yes
Modular expandability
No
Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352252004
1 NR
11.2x9.6x9.8 [cm]
137 [g]
