Three rocker push butt.+MASTER actuator - 20549

Pdf

20549
Smart systems&products / By-me Plus / EIKON / Devices

Three rocker push butt.+MASTER actuator
Three rocker push buttons and actuator for MASTER dimmer 230 V~ 50 Hz for: 40-300 W incandescent lamps, 40-200 VA electronic transfomers, 10-120 W CFL lamps, 3-120 W LED lamps and LED electronic transfomers, protection fuse, to complete with interchangeable 1- or 2-module buttons - 3 modules

Product Status
2 - Will be discontinued

Alternative products

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
3
Number of modules (module system)
300
Number of poles
1
Nominal voltage
230 V
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
67,30 mm
Device height
49,00 mm
Device depth
44,45 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352461154
1 NR
11.2x9.6x9.8 [cm]
156.6 [g]
