1P NO 10A push button Vintage bronze - 22008.12

Pdf
Vimar - 22008.12 - 1P NO 10A push button Vintage bronze
Vimar - 22008.12 - 1P NO 10A push button Vintage bronze
22008.12

Eikon EXÉ / Devices / Vintage and Flat devices

1P NO 10A push button Vintage bronze
1P NO 10A push button Vintage bronze

Product Status
3 - Active

Drawings

view encumbered art. 22008.12
PNG DXF
rear view art. 22008.12
PNG DXF
3D view art. 22008.12
PNG DXF
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Metal
Material quality
Other
Surface protection
Lacquered
Surface finishing
Matt
Colour
Bronze
RAL-number (similar)
7008
Transparent
No
Label space/information surface
Yes
Height of device
48,80 mm
Depth of device
54,60 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

15. CCC - China

19. NOM - Mexico

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352623408
1 NR
5.1x6.5x2.7 [cm]
29.7 [g]
Barcode Qty 10 NR
8007352623415
10 NR
14.5x11x7.4 [cm]
345 [g]
