Plate 5Mx10 BS Flat anthracite grey - 22699.03

Pdf
22699.03

Eikon EXÉ / Cover plates / Vintage and Flat metal cover plate

Plate 5Mx10 BS Flat anthracite grey
5-module BS cover plate for ten Flat controls, metal, anthracite grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
10
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
2
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
2
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7043
Transparent
No
With hinged lid
Yes
Type of fastening
Clamp mounting
Width
159,30 mm
Height
90,00 mm
Depth
7,15 mm
Built-in width
159,30 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352656659
1 NR
16.5x9.5x1.4 [cm]
216 [g]
Barcode Qty 5 NR
8007352656666
5 NR
17.5x8x10.4 [cm]
1,145.4 [g]
