Digibus+S.S. volume adjustment moduleCode 6153

Download as PDFPDF

6153: ELVOX Door entry system / Digibus video entry system / Indoor stations / Petrarca Series
Digibus+S.S. volume adjustment module: 4-position switching module for Digibus and Sound System installations with Petrarca interphones. The module is used for setting the call volume to one of three levels and disabling the acoustic call signal. The latter status is indicated by means of a red LED. To be fitted in the appropriate seat after removing the blank module. A green LED indicates that the door is open when connected to a suitable lock or door. Used with interphone 6204, it allows activation of the User Away function
Product Status: 3 - Active

Sheets, Manuals, Documentation

Multilanguage installer manual (1097 kb)

Class group
Communication technique (components and systems)

Class
Additional device for door communication

Function
Controlling

Installation technique
Multi-wire system

Material
Other

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

8013406161765

12x15x3 [cm]

36 [g]

8013406224453

11.5x10x8.5 [cm]

210 [g]
