IP55 surface consumer unit 3M+door grey - V51003

Pdf
V51003

Consumer units / Surface mounting / IP55 consumer units

IP55 surface consumer unit 3M+door grey
Surface mounting consumer unit with horizontally hinged transparent door, 3 (1+2) modules, RAL 7035 grey. Delivered with screwcaps for double insulation. Pre-set for 2 supports for earth terminal blocks V51855

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Small distribution board
Mounting method
Surface mounted (plaster)
Number of rows
1
Width in number of modular spacings
3
Type of cover
Door
Cover model
Closed
Transparent cover/door
Yes
Material housing
Plastic
Height
175,00 mm
Width
84,00 mm
Depth
112,00 mm
Built-in depth
0,00 mm
Internal depth
111,00 mm
DIN-rail
Yes
With mounting plate
No
Extension possible
No
EMC-version
No
Colour
Grey
RAL-number
0
Degree of protection (IP)
IP55
With lock
No

00. CE Marking - EU

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352078895
1 NR
8.4x17.5x11.2 [cm]
286.8 [g]
Barcode Qty 15 NR
8007352078901
15 NR
32x59x22 [cm]
4,912.67 [g]
