Flush mounting box for V53036 - V53936

Pdf
Vimar - V53936 - Flush mounting box for V53036
Vimar - V53936 - Flush mounting box for V53036

V53936
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

Flush mounting box for V53036
Mounting box for 36-module consumer unit V53036..., light blue

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Empty cabinet
Mounting method
Flush-mounted
Cover model
None
Transparent cover/door
No
Nominal current (In)
0 A
Height
520 mm
Width
290 mm
Depth
92,20 mm
Built-in depth
92,20 mm
Inner depth
91,20 mm
Colour
Other
RAL-number
0
Number of modules
36
Number of rows
3
Width in number of modular spacings
36
Extension possible
No
Suitable for outdoor use
No
Degree of protection (IP)
IP40
Protection class
II
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352091313
1 NR
29x52x9.2 [cm]
656.07 [g]
Barcode Qty 4 NR
8007352091320
4 NR
59x38.5x30 [cm]
3,459.33 [g]
