Coaxial cable 75ohm PVC Eca 200m - 0002.060.E

Pdf
Vimar - 0002.060.E - Coaxial cable 75ohm PVC Eca 200m
Vimar - 0002.060.E - Coaxial cable 75ohm PVC Eca 200m
0002.060.E

ELVOX CCTV / Accessories / Cables and connectors

Coaxial cable 75ohm PVC Eca 200m
Coaxial cable, 75 ohm, 3 mm cable diameter, with PVC sheath, CPR Eca class, suitable for installation with I Category power supply cables (U0 = 400 V), grey - 200 m reel

Product Status
3 - Active

Class group
Cables
Class
Coaxial cable
Inner conductor material
Other
Inner conductor category
Class 6 = very flexible
Diameter outer conductor
3,00 mm
Outer conductor material
Aluminium
Type of outer conductor
Other
Dielectric
Solid PE (HD-PE)
Armouring/reinforcement
None
With rodent protection
No
Material outer sheath
Polyvinyl chloride (PVC)
Colour outer sheath
Grey
UV resistant
No
Outer diameter approx.
3,00 mm
Approved type of underground installation
Other

00. CE Marking - EU

43. UKCA mark - Great Britain

Minimum order quantity: 200 M

Barcode

Barcode Qty 1 M
8013406301000
1 M
100x0.34x0.134 [cm]
14.08 [g]
Barcode Qty 200 M
8013406301017
200 M
24x24x8.5 [cm]
2,816 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
