Multi-outlet 3P30+4P17/11 white - 00424.B

Pdf
Vimar - 00424.B - Multi-outlet 3P30+4P17/11 white
Vimar - 00424.B - Multi-outlet 3P30+4P17/11 white

00424.B
Portable installation / Plugs and socket outlets / Multiple socket outlets / 400 series multiple sockets

Multi-outlet 3P30+4P17/11 white
2P+E 16 A 250 V~ multiple portable socket outlet, white: 3 SICURY outlets, Italian standard P30 (lateral and central earth contacts) + 4 SICURY Bpresa outlets, Italian standard P17/11

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 00424.B
PNG DXF
rear view art. 00424.B
PNG DXF
3D view art. 00424.B
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet combination
Housing shape
Rectangular
Number of socket outlets CEE 7/16 (EURO)
0
Number of socket outlets with protective contact CEE 7/3 (type F)
3
Number of socket outlets with earth pin
0
Number of cold device socket outlets
0
Number of socket outlets Italian standard type Bipasso
4
Number of socket outlets Italian standard type P11
0
Number of socket outlets Italian standard type P17
4
Number of NEMA-outlets
0
Number of socket outlets Swiss standard type 13
0
Number of socket outlets Swiss standard type 15
0
Number of socket outlets Swiss standard type 23
0
Number of socket outlets Swiss standard type 25
0
With on/off switch
No
Residual current circuit breaker (RCCB)
No
Number of universal multi standard sockets
7
Mains filter
No
Number of other socket outlets
0
Number of USB connections
0
Over voltage protection
No
Nominal current
16 A
Core cross section
0,00
With cover
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9016
Transparent
No
Degree of protection (IP)
IP20
Length of power cord
0,00 m
Rotated central insert
No
Angle rotated central insert
Other
NEMA designation
None

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352129733
1 NR
31x5.2x4.2 [cm]
263 [g]
Barcode Qty 10 NR
8007352129740
10 NR
35x29.8x9.2 [cm]
2,768.5 [g]
