Supply unit 320mA KNX - 01500.2

Pdf
01500.2

Surface mounting equipments / Systems / KNX

Supply unit 320mA KNX
Power supply unit for home automation with Bus output of 30 Vdc 320 mA, auxiliary output 30 V d.c., power supply 120-240 V~ 50/60 Hz, with decoupling coil, KNX standard, installation on DIN rail (60715 TH35) occupies 4 17,5 mm modules

Product Status
4 - Active

Class group
Installation bus systems
Class
Power supply for bus system
Bus system KNX
Yes
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Mounting method
Other
Width in number of modular spacings
4
With LED indication
Yes
Bus voltage stockable
Yes
Number of lines to feed
2
Max. output current
320,00 mA

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352550131
1 NR
11.7x10.8x7.1 [cm]
262.4 [g]
