4 inputs/outputs interface for LED KNX - 01515.1

01515.1
Smart systems&products / KNX / Shared components / Non-modular components

4 inputs/outputs interface for LED KNX
Interface with 4 channels, programmable as voltage-free contact inputs or as outputs for LEDs, KNX standard

Product Status
3 - Active

Alternative products

01514 - 2 inputs/outputs interface LED KNX

You may also be interested in

00936.5.A - LED unit 5V 0,01W amber

00936.5.B - LED unit 5V 0,01W lightblue

00936.5.G - LED unit 5V 0,01W green

00936.5.R - LED unit 5V 0,01W red

00936.5.W - LED unit 5V 0,01W white

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (452 kb)
• Installer manual (1848 kb)
• Manuale installatore (2559 kb)

Product Software

• DB_ComponentiAutomazione_KNX_01.16_20210920.zip
• DB_ComponentiAutomazione_KNX_01.19_20230331.zip
• DB_ComponentiAutomazione_KNX_01.20_20240917.zip
• DB_ComponentiAutomazione_KNX_01.21_20250224.zip

---

Drawings

PNG DXF

Class group
Installation bus systems

Class
I/O device for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequency)
No

Bus system radio frequency
No

Bus system LON
No

Bus system Powernet
No

With bus connection
Yes

Number of inputs
4

Rated current
2,50 A

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352605992

1 NR

10.8x2.4x8 [cm]

38.2 [g]
