EnOcean 2-relay actuator lighting - 01798

Pdf
Vimar - 01798 - EnOcean 2-relay actuator lighting
Vimar - 01798 - EnOcean 2-relay actuator lighting

01798
Smart systems&products / Smart switch&sound / Shared components / Non-modular components

EnOcean 2-relay actuator lighting

Product Status
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Radio frequent bidirectional
Yes
Mounting method
Other
Width in number of modular spacings
0
Local operation/hand operation
Yes
With LED indication
No
Number of digital inputs
2
Suitable for C-load
No
Max. number of switching contacts
2
Rated current
5 A
Rated operating voltage
230,00 - 230,01 V
Different phases connectable
No
With bus connection
No
Bus module detachable
No
Modular expandability
No
Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352722859
1 NR
5.1x4.3x5.3 [cm]
54.8 [g]
Barcode Qty 6 NR
8007352729049
6 NR
14.4x11.6x6 [cm]
386 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
