Transformer 20-105W - 01860.105

Pdf
01860.105

Lighting components / Devices / Transformers

Transformer 20-105W
Dimmable electronic transformer for extra low voltage halogen lamps, 20-105 W 12 V~ (SELV) output, supply voltage 230-240 V~ 50-60 Hz

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Class group
Light control
Class
Transformer for low voltage light system/low voltage halogen lamp
Type of transformer
Electronic transformer
Safety transformer
Yes
Input voltage
230 - 240 v
Output voltage
9 - 15 v
Power
20 - 105 W
Connection type primary side
Screw connection
Connection type secondary side
Screw connection
Surface-mounted
Yes
Built-in
Yes
Material housing
Plastic
Colour
Other
Short-circuit protected
Yes
Overload protection
Yes
Overtemperature protection
Yes
With secondary automatic circuit breaker
No
Number of output positions (pairs)
2
Length
39 mm
Width
149 mm
Height
27 mm
Diameter
0 mm

09. VDE - Germany

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352240483
1 NR
15.2x4.1x3.3 [cm]
135.13 [g]
