KNX cable 2x2x0,8mm LSZH Eca 100m green - 01890.E

Pdf
01890.E

Surface mounting equipments / Systems / Cable

KNX cable 2x2x0,8mm LSZH Eca 100m green
KNX system cable, 2x2x0,8 mm cable, LSZH sheath, CPR Eca class, according to KNX standard, suitable for installation with I Category power supply cables (U0 = 400 V), green - 100 m reel

Product Status
3 - Active

Class group
Cables
Class
Data and communication cable (copper)
Diameter conductor
0,80 mm
Nominal cross section conductor
0,50
Conductor category
Class 1 = solid
Number of cores
4
Stranding element
Pairs
Core insulation material
Other
Core identification
Colour
Screen over stranding element
None
Screen over stranding
Foil
Material outer sheath
Other
Colour outer sheath
Green
Halogen free (acc. EN 60754-1/2)
Yes
Flame retardant
In accordance with EN 60332-1-2
Low smoke (acc. EN 61034-2)
Yes
Outer diameter approx.
6,00 mm
Permitted cable outer temperature during assembling/handling
-20 - 80 °C
Category
Other
Minimum order quantity: 100 M

Barcode

Barcode Qty 1 M
8007352574601
1 M
100x0.6x0.6 [cm]
55.93 [g]
Barcode Qty 100 M
8007352574618
100 M
27x27x11 [cm]
5,593 [g]
Barcode Qty 300 M
8007352599086
300 M
38x34x24 [cm]
17,279 [g]
