Hi-Fi amplifier 2outs 8ohm 10-10W - 01901

01901
Smart systems&products / By-me Plus / Shared components / DIN devices

Hi-Fi amplifier 2outs 8ohm 10-10W
Stereo amplifier, 2 outputs for speakers 8 ohm 10+10 W, power supply 110-230 V 50-60 Hz, built-in line terminator, installation on DIN rail (60715 TH35), occupies 6 17,5 mm modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data
• Questions and answers

Sheets, Manuals, Documentation

• Sound System technical catlogue - IT (32460 kb)
• Multilanguage instructions sheet (654 kb)
• By-me automation-fw Compatibility (206 kb)

Video

• Configuring a mini speaker system
• Sound system

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Analogue actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Mounting method
Other

Width in number of modular spacings
6

Model
Base module

With LED indication
Yes

With bus connection
Yes

Number of outputs
2

Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352400078

1 NR

11.7x10.8x7.1 [cm]

280.84 [g]

Question:	Can I connect just one speaker to amplifiers 01901, 14581, 20581?
Answer:	Yes, in this case you must terminate the unused amplifier channel with a 100 Ohm 1Watt resistance.

---
