LED emergency lamp Eikon/Arké/Plana - 02662.120

Pdf
02662.120

Surface mounting equipments / Devices / Emergency lighting fittings

LED emergency lamp Eikon/Arké/Plana
LED lamp, supply voltage 120 V~ 50 Hz, from MASTER dimmer or ON/OFF device control, with automatic emergency device, 3 replaceable and rechargeable 1,2 V AAA batteries, 3 hours of operating range - 3 modules. To complete with Eikon, Arké or Plana cover plates

Product Status
3 - Active

Class group
Luminaires
Class
Emergency luminaire
Monitoring equipment
None
Wiring system
Standby switching
With remote switch connection
Yes
Power supply system
Peripheral (individual battery)
Battery quality
NiMH
Lamp type
LED not exchangeable
With light source
Yes
Colour housing
White
Voltage type
AC
Nominal voltage
120,00 - 120,01 v
LED nominal current at constant current
35,00 - 35,01 mA
Degree of protection (IP)
IP40
Protection class
II
Max. system power
2,50 W
Rated luminous flux according to IEC 62722-2-1
50
Width
67,30 mm
Height/depth
48,50 mm
Length
49,00 mm
Built-in width
67,30 mm
Built-in height/depth
39,00 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352487819
1 NR
11.2x9.6x9.8 [cm]
171.5 [g]
