Flat/Tondo 1P NO 24V 4-button device 2M - 02686.AX

02686.AX
Wiring devices / Traditional wiring devices / EIKON / Devices

Flat/Tondo 1P NO 24V 4-button device 2M
Control device with four push buttons 1P NO 24 VDC 50 mA max., to be completed with Flat interchangeable buttons, lighTable - 2 modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Light Multilanguage instructions sheet (530 kb)
• Full Multilanguage instructions sheet (1037 kb)

Class group
Domestic switching devices

Class
Push button

Number of modules (module system)
200

Nominal voltage
24 V

Rated current
50,00 A

Material
Plastic

Material quality
Thermoplastic

Surface finishing
Matt

Colour
Other

RAL-number (similar)
9004

Transparent
No

Label space/information surface
Yes

Device width
44,80 mm

Device height
49,00 mm

Device depth
22,20 mm

00. CE Marking - EU

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

---

Barcode

8007352656871

1 NR

5.1x4.3x5.3 [cm]

32 [g]

8007352656888

10 NR

26.9x11.6x4.9 [cm]

383 [g]
