IoT connected ceiling radar sensorCode 02692
- 02692
- Wiring devices / View Wireless wiring devices / Shared components / Non-modular components
- IoT connected ceiling radar sensor
- UWB radar sensor, IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system, 1 solid state output for extra low voltage controls (SELV and non SELV), 1 input for external push button for output activation or to recall a scenario, 100-240 V 50/60 Hz power supply, false ceiling installation
- Product Status
- 3 - Active
You may also be interested in
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (1515 kb)
- ورقة الإرشادات Full (1570 kb)
- Foglio istruzioni Full (1456 kb)
- Feuille d’instructions Full (1455 kb)
- Hoja de instrucciones Full (1454 kb)
- Full instructions sheet (1451 kb)
- Anweisungsblatt Full (1455 kb)
- Φυλλάδιο οδηγιών Full (1592 kb)
- Manuale app View Wireless (19693 kb)
- Manuel appli View Wireless (43543 kb)
- Manual app View Wireless (43542 kb)
- Manual View Wireless app (42589 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43825 kb)
- Installationsanleitung View Wireless (43598 kb)
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Movement sensor/presence detector complete
Movement sensor/presence detector complete
Model
Movement sensor
Movement sensor
Constant light control
No
No
HVAC-control
No
No
Forced switch on
Yes
Yes
Forced switch off
No
No
Animal zone
Yes
Yes
Creep-under protection
No
No
Networkable
Yes
Yes
Scan angle
90
90
Staircase light controller
No
No
Bridging switch
No
No
Max. presence range
28 m2
28 m2
Max. reach frontally
4 m
4 m
Diameter reach on floor
6,00 m
6,00 m
Suitable for wireless transmission
Yes
Yes
Remote operation
Yes
Yes
With remote control
No
No
Response value sensitivity adjustable
Yes
Yes
With signal unit
Yes
Yes
Teach-function for response value luminosity
No
No
Dim function with dimmer basic element
No
No
Mounting method
Other
Other
Suitable for ceiling mounting
Yes
Yes
Connection type
Screwed terminal
Screwed terminal
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Anti-bacterial treatment
No
No
Colour
Other
Other
RAL-number (similar)
9003
9003
Transparent
No
No
Degree of protection (IP)
IP40
IP40
Voltage type
AC
AC
Frequency
50 - 60 HZ
50 - 60 HZ
Min. switch-on time
70 s
70 s
Switch-off delay
1.080 s
1.080 s
Max. switching power
960,00 W
960,00 W
Number of switching zones
1
1
Min. starting current
0 A
0 A
Substation input
No
No
With alarm function
Yes
Yes
Width
90,00 mm
90,00 mm
Height
90,00 mm
90,00 mm
Depth
71,60 mm
71,60 mm
Diameter
90,00 mm
90,00 mm
Built-in depth
68,30 mm
68,30 mm
Built-in length
54,50 mm
54,50 mm
Built-in diameter
54,50 mm
54,50 mm
Compatible with Apple HomeKit
Yes
Yes
Compatible with Google Assistant
Yes
Yes
Compatible with Amazon Alexa
Yes
Yes
37. Marking - Morocco
40. Bluetooth technology
Minimum order quantity: 1 NR
Barcode
8007352709492
1 NR
11x8x7.7 [cm]
111 [g]
8007352709508
20 NR
43.5x33x12 [cm]
2,714 [g]
