Home autom.dial thermostat 2M white - 02971.B

Pdf
02971.B

Surface mounting equipments / Systems / Comfort - climate devices

Home autom.dial thermostat 2M white

Product Status
4 - Active

Sheets, Manuals, Documentation

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Connection
Two-wire
With receiver
No
Measuring range minimum value
0 °C
Measuring range maximum value
40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Heating
Yes
Number of heater outputs
1
Cooling
Yes
Number of cooler outputs
1
Differential value
0,00 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush mounted (plaster)
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Max. contact voltage
29 v
Max. contact load
0 A
Degree of protection (IP)
IP20
Explosion-proof
Yes
Colour
Clear white
RAL-number
1013
Height
49,00 mm
Width
44,80 mm
Depth
41,50 mm
Diameter
0 mm
Class of the temperature control
V
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352668478
1 NR
5.7x5.3x7.7 [cm]
75.2 [g]
Barcode Qty 70 NR
8007352668485
70 NR
39.5x30x17 [cm]
5,658 [g]
