02972.M
Smart systems&products / KNX / Shared components / Devices
Dial thermostat KNX 2M Metal
Product Status
3 - Active
Class group
Stats, switches and controllers
Stats, switches and controllers
Class
Room thermostat
Room thermostat
Model
On/Off
On/Off
With receiver
No
No
External sensor
Yes
Yes
Control characteristic
PID
PID
Suitable for heating
Yes
Yes
Number of heater outputs
1
1
Number of cooler outputs
1
1
Differential value
0,00 - 1,00 k
0,00 - 1,00 k
Adjustable differential
Yes
Yes
Temperature readable
Yes
Yes
With sound indicator
No
No
Sensor/feeler type
Resistance sensor
Resistance sensor
Mounting method
Flush-mounted
Flush-mounted
Number of modules (module system)
2
2
With display
Yes
Yes
Operation
Turn
Turn
With tap water circuit
No
No
Max. contact voltage
29 V
29 V
Degree of protection (IP)
IP20
IP20
Explosion-proof
Yes
Yes
Colour
Silver
Silver
RAL-number
0
0
Diameter
0 mm
0 mm
Class of the temperature control
V
V
00. CE Marking - EU
37. Marking - Morocco
92. RoHS UAE
Minimum order quantity: 1 NR
Barcode
8007352688520
1 NR
6x5.4x5.2 [cm]
45 [g]
8007352746442
60 NR
37.5x30x13.5 [cm]
3,060 [g]
